Size replacement drawer fronts from the cabinet opening, planned overlay or inset, and surrounding reveals—not from the old part alone. The existing front may be the wrong size, or the cabinet, drawer box, and adjacent openings may have changed.
Before ordering, decide whether the new drawer fronts will overlay the cabinet face or sit inside the opening. Then record the front style, thickness, grain direction, edge profile, finish, hardware position, and attachment method.
Drawer Fronts: Slab or Frame-and-Panel Fit
A slab front is one flat piece of wood, plywood, or furniture board. It suits modern cabinetry and makes dimensions, grain direction, and edge treatment easy to specify. A solid-wood slab may require seasonal movement allowance, especially across its width.
A frame-and-panel front has rails and stiles around a center panel. The panel can be flat, raised, or recessed. Measure the outside dimensions of the complete face, not the panel alone. Specify the frame width, panel profile, and whether the panel is finished to match the surrounding doors.
The front may be wider or taller than the drawer box. That is normal for an overlay installation. The box carries the drawer load and connects to the slides; the front covers the cabinet opening and provides the visible surface. Keep the front centered on the box unless the cabinet layout requires an intentional offset.
Match the door style closely. Check the wood species, stain or paint color, sheen, edge profile, and corner detail. A square-edged slab beside profiled doors will look different even when its color matches. For frame-and-panel work, match rail and stile proportions as well as the center-panel design.
Use the term drawer face for the visible front panel when communicating with a cabinetmaker. Confirm whether a quoted dimension describes the complete outside face or only the drawer-box opening. Those are different measurements.
Measure Cabinet Drawer Fronts: Overlay, Inset, and Reveals
Remove the existing front if possible, then inspect the opening, box, slides, and neighboring doors. Do not use the old part as your only template. Measure the cabinet opening and compare it with the surrounding fronts, because an earlier replacement may already be incorrectly sized.
For an overlay front, measure the opening width and height. Add the intended overlay at both sides for the finished width, and add the intended overlay at the top and bottom for the finished height:
- Front width: opening width plus left and right overlay.
- Front height: opening height plus top and bottom overlay.
For example, a 20-inch opening with a 1/2-inch overlay at each side requires a 21-inch-wide front. A 5-inch opening with a 1/2-inch overlay at the top and bottom requires a 6-inch-high front.
Do not assume every overlay is 1/2 inch. Measure nearby doors and drawer fronts from the cabinet face to their edges. Also measure the reveal between stacked fronts. The space between two fronts depends on the cabinet rail width and both overlays. If the upper front extends downward farther, the lower front must leave enough clearance to preserve the target reveal.
Many cabinets use a reveal near 1/8 inch, or 3 mm, but the correct target is the existing design. Use a consistent reveal around the new front and compare it with adjacent doors. A smaller reveal may bind after paint or seasonal movement; a larger one may look uneven.
For an inset front, measure the actual opening at several points. Record the smallest width and height, then subtract the desired reveal from both sides and from the top and bottom:
- Inset width: smallest opening width minus left and right reveals.
- Inset height: smallest opening height minus top and bottom reveals.
Check the opening for square by comparing diagonal measurements. If the diagonals differ, the front may need a slightly unequal reveal or the cabinet may need correction first. An inset front that is perfectly rectangular will not align well in a twisted opening.
Measure the drawer box separately. Note its outside width, height, front-to-back depth, slide position, and distance from the cabinet edges. Confirm that the new front will not hit the box, slides, face frame, hinges, or neighboring hardware. If the box sits off-center, mark that relationship before removing the old front.
Order or Make Replacement Drawer Fronts: Grain, Finish, and Hardware
Give the supplier the finished front dimensions, not just the opening size. State whether the dimensions are for overlay or inset installation, and identify which edge is the top. Include a sketch if the front has an asymmetric grain, profile, or drilling pattern.
For slab fronts, specify grain direction. Horizontal grain can make a wide front appear lower and is common in some modern designs; vertical grain often follows the cabinet doors. Keep grain orientation consistent across a bank of drawers. Bookmatched or cathedral grain also needs a clear sequence from top to bottom.
Specify the front thickness and every visible edge. A square edge, eased edge, round-over, bevel, or applied molding changes the finished size and how the front meets adjacent pieces. Ask whether the back is finished, raw, or relieved. A relief on the back may be necessary when the front sits over a face frame or when screw heads need clearance.
For painted fronts, confirm the paint color, sheen, and whether the edges receive the same number of coats as the face. For stained or clear-finished wood, identify the species and finish system. The same stain can look different on maple, oak, and poplar.
Decide when to drill pull holes. Factory drilling is useful when every front uses the same center-to-center spacing, but provide a precise reference from the finished edges. If fronts are not yet aligned or their dimensions changed, attach them first and drill on site with a cabinet hardware template.
Mark hole locations from the front’s finished edges, not from the drawer box. Check that the pull will clear nearby doors and that screw length suits the front thickness. For a thick front, use the pull manufacturer’s recommended screw length or add the correct spacers.
Align the Drawer Face: Shims, Fastening, and Checks
- Remove the old front. Open the drawer and support the front while removing screws from inside the box. If it is glued, score the joint carefully and protect the box from splitting. Remove leftover adhesive and mark the box centerline.
- Prepare the new front. Place it face down on a protected surface. Mark its centerline and the intended top edge. Transfer the drawer-box centerline to the inside of the front, but do not rely on that line alone for final alignment.
- Set temporary support. Close the empty opening and position the front against the cabinet. Use thin spacers or shims beneath and beside it to establish the planned reveals. Painter’s tape or a small amount of double-sided tape can hold a light front temporarily; temporary screws through the inside of the box provide stronger positioning.
- Align against neighboring fronts. Check the left and right reveals first, then the top and bottom. View the front from several feet away and place a straightedge across adjacent faces. Adjust the shims until the front is flush, evenly spaced, and centered over the box.
- Fasten from inside. Pull the drawer open without disturbing the front. Drive screws through the existing box holes or use new pilot holes. Use washers when needed to spread pressure, and choose screws that enter the front without penetrating its finished face. Tighten gradually, alternating sides so the front does not shift.
- Drill the hardware. If holes were not factory-drilled, use a template and confirm the pull position against adjacent hardware. Drill from the finished face with a sharp bit, using backing material or controlled pressure to prevent blowout. Install the pull and tighten it without crushing the wood.
- Test the drawer. Open and close it repeatedly. Check that the slides remain smooth, the front clears the cabinet, and the reveals stay even when the drawer is fully open and closed. Make small adjustments by loosening the inside screws, shifting the front against the shims, and retightening.
Finish by checking every drawer in the bank together. A front can operate correctly alone yet reveal a height or spacing error beside its neighbors. Correct alignment before adding bumpers or final screw tightening.
